Right pneumonectomy for carcinoid tumor extending through the intermediate bronchus and the interlobar artery

Introduction

Minimal invasive techniques are on an increasing demand nowadays all over the world. Obviously thoracoscopic surgery were following the steps of laparoscopic surgery in the early years of its lunch with nearly the same instruments and techniques until thoracic surgeon start to get more familiar with the scopes and start to develop their own path for learning and using minimal invasive approaches. Uniportal video-assisted thoracic surgery (VATS) is the emerging technique in the modern thoracic surgery practice.

In Egypt, thoracoscopic surgery was performed for minor procedures with limited numbers of trials to initiate VATS lobectomy program. Assiut University in one of the leading universities in Egypt which harboring compound University Hospitals 4,200 beds capacity. Assiut University cardiothoracic surgery department initiate a VATS program in 2012 and a VATS lobectomy program in 2015 with four cases of lobectomies done through two ports approach in the first year.in February 2016, we organize the 2^nd Assiut VATS workshop in collaboration with Prof. Diego Gonzalez during which we perform the first case of uniportal VATS right pneumonectomy in Egypt. Dr. Diego Gonzalez-Rivas is a world pioneer thoracic surgeon and expert in uniportal VATS. He has performed the first uniportal VATS lobectomy on 29^th of July, 2010. Since then, this innovative technique has been adopted in many countries across the world (1).

Patient selection and workup

Twenty-three years old female patient complain of hemoptysis of 8 months’ duration. She was diagnosed as having tuberculosis on a clinical suspension in another hospital and received anti tuberculous treatment for 6 months with no improvement then referred to our hospital where she underwent fiberoptic bronchoscopy that revealed endobronchial tumor at the right intermediate bronchus, biopsy was taken and pathologist report a benign endobronchial tumor. CT scan chest showed a mass 5 cm in maximum diameter extend from the right intermediate bronchus to the surrounding lung tissue with areas of calcifications (Figure 1). Lab investigation were normal, pulmonary function showed normal spirometer.

Figure 1 CT scan chest showing mass extending from the right intermediate bronchus.

Pre-operative preparation

Surgery was planned as uniportal VATS right middle and lower lobectomy. Induction of anesthesia with single lumen tube though which surgeon perform a fiberoptic bronchoscopy to confirm tumor location then a double lumen endotracheal tube was inserted. Patient positioned in lateral decubitus position and a 3 cm port was opened in the 5^th intercostal space just lateral to the anterior axillary line.

Equipment preference card

A 30°thoracoscope attached to a high definition camera (Image-1 system, Karl Storz Inc., Tuttlingen, Germany), specially designed curved thoracoscopic instruments, endostaplers, energy sealing device and vascular clips were used (Figure 2).

Figure 2 Surgeon and assistant stand in front of the patient.

Procedure

The camera was placed in the most superior part of the incision and the instruments were placed below the camera. Inspection of the chest cavity revealed extensive adhesions between the lung and chest wall (Figure 3) lysis of adhesions using Harmonic sealing device (Harmonic energy device, Ethicon Co., USA). The lung was retracted cranially and the inferior pulmonary ligament was divided using Harmonic to expose the inferior pulmonary vein which was divided using articulating vascular stapler. Trial to expose the interlobar artery inside the fissure revealed that the artery was incased by the tumor with no sparing to the upper and middle lobe branches so the decision was to go for right pneumonectomy. Division of the main bronchus followed by the superior vein then the main right pulmonary artery was done. Extraction of the specimen through an endo-bag (Figure 4). A single chest tube was inserted through the same incision and placed posteriorly at the end of the procedure (Figure 5).

Figure 3 Demonstrate the position of the surgeon, assistants and scrub nurse site of port placement, lysis of adhesions and skin suture to retract the soft tissue (2). Available online: http://www.asvide.com/articles/962

Figure 4 Demonstrate surgical steps; division of the inferior pulmonary vein, superior pulmonary vein, bronchus and pulmonary artery then retrieval of the specimen (3). Available online: http://www.asvide.com/articles/963

Figure 5 A chest tube through the same incision.

Post-operative management

The vital signs of the patients were stable during the surgery with estimated blood loss of about 800 cc. After returning to supine position the patients were extubated and were transferred to the critical care unit. The patients were allowed to drink and eat after 2 hours and were sent back to the thoracic surgery department ward next morning. Recovery after the surgery was fast and easy. Postoperative pain was minimal; chest X-ray was excellent (Figure 6). Chest tube was removed after 2 days and the patient was discharged to home on 3^rd day postoperative. Final pathology report was typical carcinoid tumor that 1 cm away from the bronchial and vascular surgical margin.

Figure 6 Postoperative chest X-ray.

Tips, tricks and pitfalls

• The camera was placed in the most superior part of the incision and the instruments were placed below the camera;
• A long gauze wrapped around the scope can be used by the assistant to fix the camera at the superior part of the incision at all the time (Figure 7);
• A silk suture can be taken on the skin edge of the incision to retract the soft tissue away instead of use of soft tissue retractor.

Figure 7 Gauze wrapped around the scope to fix it in its superior position.

Comments

In spite of the limited budget of health system in the developing countries, we committed to provide our patients with the best available health care. We started our VATS program in Assiut University in 2012, more cases were done every year with publication of our initial experience (4). The direction towards uniportal VATS was a dream taking to catch up with the cutting edge of knowledge in thoracic surgery and the workshop with live case transmission was the initial step. The workshop was attended by 84 thoracic surgeons from all across Egypt with a high motivation for adopting the technique in the everyday practice. We believe that uniportal will be the first choice approach for thoracic surgeon in Egypt in the upcoming year.

Acknowledgements

The workshop was supported financially by Ethicon.

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

References

1. Gonzalez-Rivas D, Paradela M, Fernandez R, et al. Uniportal video-assisted thoracoscopic lobectomy: two years of experience. Ann Thorac Surg 2013;95:426-32. [Crossref] [PubMed]
2. Elkhayat H, Gonzalez-Rivas D. Demonstrate the position of the surgeon, assistants and scrub nurse site of port placement, lysis of adhesions and skin suture to retract the soft tissue. Asvide 2016;3:206. Available online: http://www.asvide.com/articles/962
3. Elkhayat H, Gonzalez-Rivas D. Demonstrate surgical steps; division of the inferior pulmonary vein, superior pulmonary vein, bronchus and pulmonary artery then retrieval of the specimen. Asvide 2016;3:207. Available online: http://www.asvide.com/articles/963
4. Elkhayat H, Khairy M, Elminshawy A, et al. Minimal invasive approachs for intrathoracic benign disease. Tuberk Toraks 2013;61:260-2. [Crossref] [PubMed]
