S¹⁺² Segmentectomy of the left upper lobe: a good solution to preserve the pulmonary function of patients with stage I NSCLC

Introduction

Limited resections for early stage lung cancer have recently aroused increasing interests. Theoretical advantages of limited resections for early stage lung cancer include preservation of pulmonary function and potentially similar oncologic results supported by quite a few studies recently published (1-6). Several retrospective reports have demonstrated that video-assisted thoracoscopic surgery (VATS) segmentectomy for stage IA lung cancer may have survival and local recurrence rate comparable to VATS lobectomy (4,5). But it is still unclear to what extent a limited resection could preserve the pulmonary function comparing to a standard lobectomy, especially in the context of the minimally invasive surgery (7-9).

Although segmentectomy helps to spare more lung parenchyma than lobectomy, it is not necessarily associated with more pulmonary function preserved. As recently reported by Gu et al. (10), pulmonary function loss per segment resected would be almost doubled after segmentectomy than after lobectomy. And combined segmentectomy would certainly cost more functional loss than single segmentectomy. It seems that postoperative functional benefit could be expected only if at least more than half of the lung parenchyma in the corresponding lobe is preserved. Therefore, for small peripheral lung cancers located in the apico-dorsal segment of the left upper lobe, it is less likely for lingual-sparing left upper lobectomy to have significantly more functional preservation comparing to a standard left upper lobectomy. In this context, the role of S¹⁺² segmentectomy could be more beneficial comparing to a typical tri-segmentectomy, in order to preserve the pulmonary function of the patient. Here, we present a case of a patient with a minimally invasive adenocarcinoma (MIA) in the S¹⁺² segment of the left upper lobe treated with a S¹⁺² segmentectomy.

Case presentation

A 55-year-old female patient, non-smoker, with no significative past clinical history, came to us for a chest CT scan finding of a 9.8 mm subsolid nodule in the S¹⁺² segment of the left upper lobe. PET scan showed a slight FDG uptake of the pulmonary nodule. Considering it highly suspicious for neoplastic lesion, a surgical excision of the pulmonary nodule by a S¹⁺² segmentectomy was proposed. The patient was in good clinical condition, with a good cardio-pulmonary function. Patient’s informed consent was acquired before surgery. Two hours before the operation, a hook wire was inserted into the lesion under CT guidance. After intubation, the patient was placed in a right lateral decubitus position. The left arm was suspended on a frame above her head. A three-port VATS approach was selected. In the Figure 1, we show the surgical procedure. First, a camera port was created in the 7^th intercostal space on the mid-axillary line and a 10-mm 30-degree thoracoscope was introduced through a 12-mm trocar for exploration. Under the guide of the camera, a 4 cm utility port in the 4^th intercostal space, on the mid-anterior axillary line and a 20 mm assistant port in the 8th intercostal space, on the posterior axillary line were created. On exploration, the lesion was confirmed to be located in the S¹⁺² segment according to the position of the hook wire. Thus, we proceeded with the S¹⁺² segmentectomy. First, the incomplete fissure was divided. On the distal part of the fissure, between the S¹⁺² and S⁶ segments, the artery for the S² segment (A²) was identified and divided. Sometimes, it is not so easy to differentiate A² from A⁴⁺⁵. In this case, this artery clearly ran towards the S¹⁺² segment. Then, the anterior hilum of the left upper lobe was exposed to reveal the superior pulmonary vein and the left pulmonary artery; the pulmonary vein for the apical segment of the LUL (V¹) was then exposed and divided. This helped revealing the pulmonary artery branches to the apical (A¹) and the anterior (A³) segments. The subsequent step was to divide the A1 from the posterior hilum. After cutting the A¹ and A², No. 12 lymph nodes could be readily dissected, and this helped identifying the bronchus for the apico-dorsal segment of the LUL (B¹⁺²). Before cutting the B¹⁺², it is always helpful to first localize B³ nearby, and to clamp the B¹⁺² bronchus while asking the anaesthesiologist to re-expand the lung. This helps verifying the correct bronchial branch to be cut and creating a marked parenchymal inflation-deflation line to identify the S¹⁺² parenchyma. After dividing the B¹⁺², the bronchial stump was lifted up from the hilum. This permitted elevating the lung parenchyma of the S¹⁺² away from the remaining left upper lobe and allowed dissecting it as peripherally as possible. Finally, the S¹⁺² was cut by endo staplers along the lung inflation-deflation line between the deflated S¹⁺² and the inflated remaining lung. The resected specimen was then removed in a retrieving bag through the utility port. And stations 4, 5, and 7 lymph nodes were sampled.

Figure 1 Three-port VATS left apico-dorsal (S¹⁺²) segmentectomy for a MIA in the left upper lobe (11). VATS, video-assisted thoracoscopic surgery; MIA, minimally invasive adenocarcinoma. Available online: http://www.asvide.com/article/view/26658

Results

The post-operative course was uneventful, and the patient was discharged on the 4^th post-operative day. Final histopathological examination revealed a MIA of the lung, staged as pT1miN0M0. Currently, the patient is in good condition and under routine follow-up.

Conclusions

In the treatment of early stage lung cancer located in apico-dorsal segment of the left upper lobe, S¹⁺² segmentectomy is a safe and useful procedure that permits to spare more remaining segments than a typical lingual-sparing tri-segmentectomy. The combination of limited anatomical resection and minimally invasive surgical approach is beneficial for the functional preservation of the patients as long as the oncological efficacy could be maintained.

Acknowledgments

Funding: None.

Footnote

Provenance and Peer Review: This article was commissioned by the Guest Editor (Alessandro Brunelli) for the series “Uncommon Segmentectomies” published in Journal of Visualized Surgery. The article has undergone external peer review.

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at http://dx.doi.org/10.21037/jovs.2018.08.02). The series “Uncommon Segmentectomies” was commissioned by the editorial office without any funding or sponsorship. The authors have no other conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in studies involving human participants were in accordance with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient for publication of this manuscript and any accompanying images.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Oizumi H, Kanauchi N, Kato H, et al. Total thoracoscopic pulmonary segmentectomy. Eur J Cardiothorac Surg 2009;36:374-7. [Crossref] [PubMed]
2. Kilic A, Schuchert MJ, Pettiford BL, et al. Anatomic segmentectomy for stage I non-small cell lung cancer in the elderly. Ann Thorac Surg 2009;87:1662-6. [Crossref] [PubMed]
3. Henschke CI, Yankelevitz DF, Altorki NK. The role of CT screening for lung cancer. Thorac Surg Clin 2007;17:137-42. [Crossref] [PubMed]
4. Zhong C, Fang W, Mao T, et al. Comparison of thoracoscopic segmentectomy and thoracoscopic lobectomy for small-sized stage IA lung cancer. Ann Thorac Surg 2012;94:362-7. [Crossref] [PubMed]
5. Hwang Y, Kang CH, Kim HS, et al. Comparison of thoracoscopic segmentectomy and thoracoscopic lobectomy on the patients with non-small cell lung cancer: a propensity score matching study. Eur J Cardiothorac Surg 2015;48:273-8. [Crossref] [PubMed]
6. Fiorelli A, Caronia FP, Daddi N, et al. Sublobar resection versus lobectomy for stage I non-small cell lung cancer: an appropriate choice in elderly patients? Surg Today 2016;46:1370-82. [Crossref] [PubMed]
7. Keenan RJ, Landreneau RJ, Maley RH Jr, et al. Segmental resection spares pulmonary function in patients with stage I lung cancer. Ann Thorac Surg 2004;78:228-33. [Crossref] [PubMed]
8. Takizawa T, Haga M, Yagi N, et al. Pulmonary function after segmentectomy for small peripheral carcinoma of the lung. J Thorac Cardiovasc Surg 1999;118:536-41. [Crossref] [PubMed]
9. Saito H, Nakagawa T, Ito M, et al. Pulmonary function after lobectomy versus segmentectomy in patients with stage I non-small cell lung cancer. World J Surg 2014;38:2025-31. [Crossref] [PubMed]
10. Gu Z, Wang H, Mao T, et al. Pulmonary function changes after different extent of pulmonary resection under video-assisted thoracic surgery. J Thorac Dis 2018;10:2331-7. [Crossref] [PubMed]
11. Ventura L, Gu Z, Zhao W, et al. Three-port VATS left apico-dorsal (S1+2) segmentectomy for a MIA in the left upper lobe. Asvide 2018;5:712. Available online: http://www.asvide.com/article/view/26658
