Hemiarch replacement with aortic root preservation for acute type A aortic dissection

Clinical vignette

A 67-year-old man with a history of hypertension presented to our emergency department (ED) with acute onset sharp chest pain radiating to the back. A CT scan revealed an acute Type A aortic dissection (TAAD) with no signs of malperfusion and a small pericardial effusion. After discussions with the patient and informed consent, decision was made to take the patient to the operating room for immediate intervention.

Introduction

There are different schools of thought on what constitutes the optimal surgical approach for acute TAAD (1-3). While the extent of aortic root and arch pathology predicates the minimal intervention necessary to restore and maintain true lumen blood flow, restore valvular competency and preserve life (i.e., tear-oriented approach in form of aortic valve resuspension and root preservation when possible along with hemiarch reconstruction), more aggressive distal procedures such as total arch replacement (TAR) with or without the use of frozen elephant trunk (FET) or classic elephant trunk (ET) technique often aim at mitigating the risk of delayed distal aneurysm formation. Extensive proximal pathology where the aortic root cannot be preserved is managed with a Bentall-type root replacement or a valve-sparing root replacement (VSRR) in selected patients, while arch aneurysms or complex distal tears with distal false lumen pressurization might necessitate some sort of TAR with distal true lumen stabilization (ET/FET). The most common procedure performed at most institutions for the management of acute TAAD is hemiarch replacement in conjunction with aortic valve resuspension to preserve the aortic root.

Surgical technique

Patients are typically brought in directly to the operating room without any delay. A radial arterial line and a central venous line are inserted in addition to large bore peripheral IVs. This is done before institution of general anesthesia to be prepared for any hemodynamic compromise. The unpredictable hemodynamic nature of TAAD with potential for fast deterioration and cardiac arrest especially with transferring the patient to the operating table and during induction of anesthesia mandates both attending cardiac surgeon and experienced anesthesiologist to be in the room at all times with a plan for rapid intervention and cannulation should hemodynamic collapse occur. Routine neurocerebral monitoring is employed throughout the operative procedure using somatosensory evoked potentials (SSEP) and electroencephalogram (EEG) assessment. Transesophageal echocardiography (TEE) is utilized to confirm the diagnosis and to evaluate baseline cardiac function including degree and etiology of aortic regurgitation.

TAAD repair is performed via median sternotomy. The extent of both proximal root and distal arch repair is predicated on (I) location of primary tear, (II) presence of any large secondary tears, (III) aneurysmal sinuses of Valsalva (SOV) and aortic arch and (IV) signs of distal malperfusion. For our patient presenting with a Debakey II TAAD and a primary tear in the proximal ascending aorta and no aneurysmal dilation of the SOV, the operation of choice was an ascending and hemiarch replacement with aortic root preservation and aortic valve resuspension.

Systemic heparin is administered after the pericardium is opened and suspended. The distal ascending aorta is cannulated directly along the lesser curvature over a wire using modified Seldinger technique (Figure 1). To achieve true lumen cannulation, the aorta is punctured with an 18-gauge needle and a soft-tip J-wire was advanced into the true lumen of the proximal descending aorta under TEE guidance. The tract is then serially dilated and the arterial cannula is advanced over the wire with the tip placed distal to the left subclavian artery. A dual stage venous cannula is used venous return. In preparation for retrograde cerebral perfusion (RCP), the SVC is dissected, encircled with an umbilical tape, cannulated with a right-angled soft-tipped venous cannula and connected to the venous line with a Y-connector. Once the patient is on cardiopulmonary bypass (CPB), systemic cooling is initiated to achieve EEG silence. This typically occurs between 18–22 deg C (bladder) in our experience. A retrograde cardioplegia catheter is then paced in the coronary sinus and cross clamp is applied. While retrograde cardioplegia is being administered, the aorta is transected down to the level of the sinotubular junction (STJ). The aortic valve is inspected carefully to ensure that it is free of pathology. If the aortic root is not aneurysmal and does not have a tear, it is routinely preserved. Thrombus between the adventitia and intima is removed and a piece of Teflon felt is utilized to create a ‘neomedia’ (4) using a sandwich technique. The adventitia and intima are then sewn to each other using running 4-0 polypropylene. The aortic valve is then resuspended at the level of the commissures using pledgeted 4-0 polypropylene sutures (Figure 2). Use of biological glues is avoided due to concerns of provoking formation of delayed pseudoaneurysms (5). The STJ is then sized with an intra-annular valve sizer and a straight woven polyester graft is anastomosed to the reconstructed aortic root using running 4-0 polypropylene sutures. Antegrade cardioplegia is then infused via the Dacron graft fulfilling multiple purposes: (I) myocardial protection, (II) evaluation of valvular competency and (III) assessment of hemostasis at the suture line. Reinforcement sutures are placed as necessary at this point.

Figure 1 Cannulation strategy. Central aortic cannulation via a modified Seldinger technique under transesophageal echocardiographic guidance (TEE) is our preferred approach in the setting of acute type A aortic dissection (TAAD) and technically feasible in >90% of patients. Contraindications to central arterial cannulation include rupture of the arch, circumferential arch dissection and complex arch tears. We routinely use a dual-staged venous cannula for the right atrium and a second right-angled soft-tipped venous cannula in the superior vena cava (SVC) guided into the right internal jugular vein for retrograde cerebral perfusion (RCP). Retrograde cardioplegia is administered via a coronary sinus catheter. A left ventricular vent is advanced via the right superior pulmonary vein.

Figure 2 Proximal aortic root and valve repair. During administration of retrograde cardioplegia, the aorta is transected and trimmed to the level of the sinotubular junction (STJ), allowing inspection of the aortic root and the aortic valve. If the aortic root is non-aneurysmal and there are no intimal tears below the level of the STJ, we typically perform aortic valve suspension using pledgeted 4-0 polypropylene sutures. Retrograde medial disruptions reaching to the level of the Sinus of Valsalva are repaired by securing tailored pieces of Teflon felt between intimal and adventitia (neomedial reconstruction).

Once EEG silence is achieved indicating optimal core cooling, attention is shifted to the aortic arch. In preparation for RCP, the SVC is snared around the angled cannula and the side port of the internal jugular vein is transduced. CPB is discontinued and RCP is initiated with a goal SVC pressure of 26–30 mmHg. Effective RCP is confirmed both via achieving and maintaining goal venous pressures and visualization of dark blood emerging from the brachiocephalic vessels.

The aortic arch is inspected carefully to ensure no re-entry tears and the aorta is trimmed to the base of the innominate artery (Figure 3). Similar to the aortic root, thrombus is removed from the dissection plane and intimal-adventitial plane is reconstructed using the neomedial technique described above. The hemiarch anastomosis is then completed with running 4-0 polypropylene sutures using a second beveled Dacron tube graft after appropriate sizing. The graft is intussuscepted into the distal aorta to achieve intimal-graft apposition to ensure hemostasis (Figure 3). Upon completion of the anastomosis, the graft is cannulated with an arterial cannula. The brain, arch and the graft are de-aired thoroughly and the patient is placed back on CPB and rewarmed to normothermia. The anastomosis is inspected for and reinforced with additional sutures as needed. Both straight grafts are trimmed appropriately and beveled to mimic the natural ascending aortic curvature and the final graft-to-graft anastomosis was completed using running 2-0 polypropylene sutures (Figure 4). Hot shot cardioplegia is given, the heart is de-aired and the cross clamp is released. After an adequate period of reperfusion and a period of normothermia, the heart is allowed to fill and wean off CPB. Operative approach is detailed in Video 1.

Figure 3 Distal hemiarch anastomosis. Upon confirmation of electrocerebral quiescence retrograde cerebral perfusion is initiated and maintained at a goal venous pressure of 26–30 mmHg, arterial inflow is stopped, both arterial and venous lines are clamped and the cross-clamp is opened. Following inspection of the aortic arch, neomedial reconstruction is performed by placing tailored pieces of Teflon felt into the dissected intimal-adventitial tissue planes and the dissected aortic wall is reapproximated using running 5-0 polypropylene sutures. A Dacron graft is then sized using an intra-annular valve sizer, beveled to follow the natural curvature of the aortic arch and the hemiarch anastomosis is completed by intussuscepting the graft into the aortic arch using running 4-0 polypropylene.

Figure 4 Graft-to-graft anastomosis. Following completion of the hemiarch anastomosis, the distal graft is cannulated, thoroughly de-aired, re-clamped and cardiopulmonary bypass (CPB) is resumed. Proximal and distal Dacron grafts are then trimmed to appropriate length, beveled to follow the natural curvature of the ascending aorta and aortic continuity is established by performing a graft-to-graft anastomosis using a running 3-0 polypropylene suture.

The pericardium is opened and the innominate vein identified. Central aortic cannulation is achieved via modified Seldinger technique under TEE. A dual-staged venous cannula is inserted into the right atrium for venous drainage. We use a second right-angled soft-tipped venous cannula in the SVC guided into the right internal jugular vein for RCP. Retrograde cardioplegia is administered via a coronary sinus catheter. The aorta is transected and both aortic root and aortic valve are inspected. The aortic root is non-aneurysmal with no intimal tears below the level of the STJ and decision is made to proceed with aortic valve suspension using pledgeted 4-0 polypropylene sutures. With confirmation of electrocerebral quiescence retrograde cerebral perfusion is initiated and maintained at a goal venous pressure of 26–30 mmHg and the cross-clamp is released. The aortic arch is inspected and neomedial reconstruction with tailored pieces of Teflon felt is used to reapproximate dissected intimal-adventitial tissue planes (not shown). A Dacron graft is then sized using an intra-annular valve sizer and the hemiarch anastomosis is completed by intussuscepting the graft into the aortic arch using running 4-0 polypropylene. Following completion of the hemiarch anastomosis, the distal graft is cannulated, de-aired, re-clamped and CPB is resumed. The Dacron graft is then trimmed to appropriate length and anastomosed proximally to the level of the STJ.

Comment

TAAD remains a true surgical emergency requiring fast and complex surgical decision making and is traditionally associated with high morbidity and mortality even in experienced hands. Proper management of patients with TAAD starts with prompt diagnosis based on CT angiogram, rapid transfer to the operating room or to a center experienced in the operative management of these patients with the goal of (I) expeditious restoration of true lumen blood flow with obliteration of false lumen flow to eliminate any malperfusion, (II) resection of the primary tear site(s) and (III) restoration of valvular competency; all while ensuring optimal neurocerebral and distal organ protection via core cooling and antegrade (ACP) and/or RCP during circulatory arrest (6). In our experience, RCP is utilized during shorter periods of circulatory arrest (hemiarch replacement) while ACP is utilized for total arch reconstruction (7).

TAAD repair can necessitate a variety of surgical strategies from simple replacement of the ascending aorta, via some sort of aortic root reconstruction or replacement to various degrees of aortic arch reconstruction (hemiarch, zone II arch, total arch) with or without necessity of true lumen stabilization in the descending thoracic aorta via a FET or concomitant/staged antegrade (8-10) or retrograde TEVAR (11). As mortality improved over the past decade and started to plateau (12) debate has shifted to the extent of distal aortic repair, especially as long term morbidity is associated with pathologies of the arch rather than the aortic root (13) with up to 10–30% reintervention rate for the distal aorta following repair of acute TAAD (14). There have been repeated attempts at aggressive arch reconstructions beyond the hemiarch repair in this high-risk patient cohort to minimize the need for future distal reinterventions, but this needs to be balanced not only with increased risk of perioperative morbidity and mortality (15) but also with the surgeon’s comfort level, particularly in low volume centers. Only isolated studies have described comparable operative mortality for patients undergoing hemiarch vs. total arch reconstruction (16). At our institution, we follow an algorithmic approach based on imaging and intraoperative findings (6,14). The need for aortic arch repair (i.e., TAR) is predicated on the presence of one or more of four key findings (6): (I) presence of an aortic arch aneurysm, (II) primary, secondary or re-entry tear in the arch or proximal descending aorta, (III) circumferential dissection of the aortic arch and/or (IV) carotid dissection causing cerebral malperfusion. If none of these findings are encountered, we typically proceed down the hemiarch path which is feasible in about 60% of patients in our experience. We typically perform our hemiarch cases under deep hypothermic circulatory arrest using RCP. In our experience, aggressive hemiarch replacement under deep hypothermic circulatory arrest and RCP has been associated with excellent perioperative morbidity and mortality and long term outcomes (17,18). In about 40% of cases, we encounter one or more of the characteristics described above and proceed with a TAR. We routinely use ACP for our TAR cases.

If one or both carotids are dissected with presence of cerebral malperfusion and a neurologic deficit, our approach is to avoid malperfusion of the brain during circulatory arrest entirely. We achieve this by isolating the “culprit” carotid artery during the cooling phase by surgically isolating the carotid bifurcation. A trifurcate graft that is tunneled to the neck is then sewn to the carotid bifurcation and utilized for ACP (14). Prior to circulatory arrest, bilateral carotid arteries are reperfused so bilateral ACP can be utilized during circulatory arrest. The more complex surgical decision involves patients with radiographic evidence of carotid dissection without evidence of cerebral malperfusion (14,19).

The aortic root is probably more challenging to regiment based on preoperative imaging studies alone (14). The decision on the type and extent of root procedure is usually established in the OR after transecting the aorta. If the intimal tear is distal to the STJ and there is some retrograde propagation of the dissection flap into the sinus that is salvageable we typically resuspend the valve at the level of the commissures and perform a neomedial root reconstruction. Even if we encounter further complicating factors such as an intimal tear proximal to the STJ, involvement of the coronary ostia or root dilation we typically try to preserve the valve in terms of a VSRR, but this is largely dependent on the surgeon’s judgement, hemodynamic situation allowing longer operative times and the patient age.

Our preferred and default cannulation strategy irrespective of the extent of proximal and distal repair is central cannulation via a modified Seldinger technique and echocardiographic guidance. We are successful in centrally cannulating patients with acute TAAD in over 90% of the cases, even in cases of hemodynamic instability (6,14). The surgeon should feel 2 “pops” as the needle passes through the aortic wall via the false lumen into the true lumen (20). Contraindication to central cannulation include arch rupture, circumferential arch dissection and complex arch tears at which point axillary of femoral cannulation is used (6).

In summary, contemporary management of patients presenting with acute TAAD entails complex multidisciplinary decision making and expeditious transfer to the operating room. In a majority of patients, a strategy of aortic root preservation with hemiarch replacement can be achieved under deep hypothermic circulatory arrest with RCP. Only distinct features require a TAR.
