Video-assisted thoracic surgery right lower lobe common basal segmentectomy (S7-S8-S9-S10)

Introduction

Video-assisted thoracic surgery (VATS) anatomic segmentectomy is becoming more and more frequent surgical procedure over time, specially due to the increasing use and diffusion of minimally invasive techniques. Traditionally, this lung-sparing technique was preferred only for patients with pulmonary metastases (1-3) or patients with non-small cell lung cancer (NSCLC) and limited cardiopulmonary reserve or multiple comorbidities (4-6), as long as wedge resection is not possible. Recently, a phase III randomized control trial (JCOG0802/WJOG4607L) (7) demonstrated the benefit of segmentectomy in comparison with lobectomy revealing statistically significant differences respect to overall survival. This study concluded that segmentectomy should be the standard surgical procedure instead of lobectomy for patients with small-sized (<2 cm, CTR >0.5) peripheral c-stage IA NSCLC.

Single or combined basal segmentectomies are usually more technically complex than other types of segmentectomies because of the deeper intraparenchymal localization of the hilar structures, more frequent anatomical variations, and more challenging identification of the intersegmental planes. The aim of this manuscript is to describe the operative steps, tips, pitfalls and caveats of VATS right lower lobe common basal segmentectomy (S7-S8-S9-S10).

Anatomical landmarks

A thorough knowledge of the vascular and bronchial hiliar structures and segmental and subsegmental branches is essential before performing a segmentectomy. Table 1 shows the most frequent anatomical patterns and possible variants of the right basilar segments (8).

Preoperative planning

Contrast-enhanced high-resolution computed tomography (HRCT) scan must carefully reviewed preoperatively. First of all, the identification of the pulmonary segment where the target lesion is located should be determined based on its relationship with the segmental bronchus. In this specific segmentectomy, the pulmonary nodule must be located in the right common basal pyramid below the superior segmental bronchus (B⁶).

Then, specific segmental vessels and bronchi as well as positional relationship of these segmental structures must be analyzed to design an appropriate surgical resection. Additionally it is essential to identify preoperatively possible anatomical variants and infrequent anatomical patterns in order to avoid cutting wrong structures during the surgery. Recently, the design of state-of-art software allows to obtain precise three dimensional (3D) models of the airway and pulmonary vessels. The application of these three dimensional computed tomography bronchography and angiography (3D-CTBA) programs clearly identify pulmonary segmental and subsegmental structures, avoids intraoperative accidental injury, shortens the operation time and improves the safety of VATS segmentectomy (9).

Operative steps

Anesthesia management

General anesthesia is induced and endotracheal intubation is performed using a double lumen tube. The patient is monitored by electrocardiography, pulse oximetry, capnography and bispectral Index (BIS). An intraarterial catheter is placed for hemodynamic control. However, central venous and pulmonary artery catheterization are not routinely used. Indwelling urinary catheter is usually necessary to monitor urinary output.

Patient positioning

The patient is placed in a standard left lateral decubitus position with arms flexed and stretched toward the head on appropriate supports. An axillary roll is placed in order to raise up the chest and open the intercostal spaces. Once the patient is correctly positioned, the skin is cleaned up with a chlorhexidine-based solution and draping is prepared in the usual manner. A prophylactic dose of Cefazolin is administered.

Working incision

In this case, the pleural cavity was approached by performing uniportal technique through the fifth intercostal space at the level of the anterior axillary line. If biportal technique is preferred, an additional port (1 cm) is placed in the eighth intercostal space at the level of the posterior axillary line. A flexible Alexis^TM soft tissue wound protector (Applied Medical, Inc., Rancho Santa Margarita, CA, USA) is placed in the port rather than using a rib-spreading retractor decreasing postoperative pain. The entire procedure is performed under video-assisted visualization using a high definition 30-degree thoracoscopic camera. Before starting the surgical resection, criteria for non-resectability must be ruled out.

Note: The number of ports basically depends on the surgeon preferences. Biportal technique is also a suitable approach especially for anatomical segmentectomies. This biportal approach has several benefits. First we can put a grasper into the pleural cavity through the camera port improving the exposure and traction of the pertinent pulmonary segments. Additionally, this maneuver decrease the number of instruments through the utility port providing more comfortability to the surgeon. Second, and even more important, we can switch both the camera and the staplers in two different ports. It allows us to view the hiliar structures from different perspectives. Furthermore, we can insert the staplers from different angles decreasing the tension over the subsegmentary vessels which are specially fragile.

Pulmonary nodule identification

Visual or digital palpation and localization of the target tumor is recommended in order to confirm intraoperatively the planned segmentectomy. The width of the basal pyramid makes this decision easier than in other types of segmentectomies. The pulmonary nodule should be located far away from the intersegmental line with S6 in order to achieve an optimal surgical margin. Once the pulmonary lesion is localized, marking directly on the surface of the visceral pleura can be performed using electrocautery or sutures. This visual reference will be useful during the parenchyma division through the intersegmental plane. In case of peripheral millimetric and/or subsolid nodules such as ground glass opacities, transthoracic or bronchoscopic marking techniques can be helpful for detecting these kinds of untouchable lesions (10).

Vein (Video 1)

The pulmonary resection is initiated by sectioning the inferior pulmonary ligament. If there are any pulmonary ligament lymph nodes (Station 9) at this point, they should be removed. Once the inferior pulmonary vein is identified, both the main vein and segmental branches must be completely exposed clearing the surrounding tissues with a ultrasonic energy device. The most common anatomical pattern for the right inferior pulmonary vein is the division in the venous branch of the superior segment (V⁶) and the common basal vein. After identification of V⁶ in the posterior side of the inferior pulmonary vein, the common basal vein is dissected, encircled with a tape and divided using an angled vascular endostapler inserted from the utility port in both uniportal and multiportal approaches.

Tips and tricks: a gentle retraction of the lower lobe toward the cranial side allows to expose properly the inferior pulmonary vein.

Caveats: possible anatomical variants must be always considered (Figure 1). These anomalous venous patterns should be suspected preoperatively by checking the HRCT scan.

Figure 1 Middle lobe vein (black arrow) draining directly in the right inferior pulmonary vein.

Artery (Video 2)

This step begins by locating the pulmonary artery at the junction of the minor and the oblique fissure. When the fissure is incomplete or inflammatory, this part could be more challenging and tedious. The inferior and superior pulmonary lobes are oppositely retracted in order to expose the interlobar plane. Once the pulmonary artery is identified, this should be completely dissected including the adventitial layer. Then, A⁶ and the basal trunk are clearly visualized. There are usually several lymph nodes surrounding the basal arterial trunk, specially between A⁶ and A^9-10, and anterior to A⁷. All these lymph nodes need to be removed in order to fully expose the artery. Access to the basal trunk is facilitated by the division of the anterior portion of the oblique fissure between the middle lobe and the lower lobe. Stapling is preferable when this fissure is too thick, instead of bipolar or ultrasonic dissection. Once the anterior portion of the oblique fissure is opened, a dissecting forceps is introduced from the utility port passing the basal arterial trunk which is encircled with a tape and finally stapled.

Tips and tricks: the basal arterial trunk can be easily passed from the utility port using a curve-tip vascular stapler.

Caveats: the dissection of the fissure must be performed carefully so as to avoid troublesome oozing, parenchymal tears and postoperative air leaks.

Bronchus and intersegmental plane division (Video 3)

After cutting the basal arterial trunk, the surrounding peribronchial tissue is cleared circumferentially, including possible lymph nodes at this level. B⁶ must be also exposed. Both bronchial branches, basilar bronchus and B⁶, are clearly identify most of the times and bronchoscopic confirmation is not usually needed in this segmentectomy. Then, the basilar bronchus is passed with a dissecting forceps and referenced with an elastic tape. After clamping the basilar bronchus and ventilating the right lower lobe, the intersegmental plane between S⁶ and S^7-10 is clearly visualized.

At this point, there are two possible alternatives.

• Bronchus-first: the basilar bronchus is sectioned using an endostapler. Right lower lobe retraction towards the cranial side can facilitate this maneuver. Then, the intersegmental plane is divided from the anterior to the posterior side along the inflation-deflation line. V⁶b (between S⁶ and S⁸) and V⁶c (between S⁶ and S¹⁰) run along the intersegmental plane and these venous branches must be respected.
• Parenchyma-first: a dissecting forceps is passed between the basal bronchus and V⁶, taping this new neo-fissure. This maneuver prevents cutting V⁶ accidentally, preserving the venous drainage of S⁶. The lung tissue is cut from anterior to posterior direction using several parenchymal reloads for endostapler. Once the intersegmental plane between S⁶ and S^7-10 is completely divided, the basilar segments (S^7-10) are just hanging from the basal bronchus which is sectioned.

During parenchyma stapling, the vascular and bronchial distal stumps should always be pushed away so they will remain included in the specimen side away from the stapler jaws. Once the basal pyramid is fully disconnected, the specimen is removed into an endobag. Possible air leaks must be tested insufflating the lung under the water.

Tips and tricks: a long clamp can be applied on the parenchyma, especially when the intersegmental tissue is too thick. This compression makes the stapler application easier.

Caveats: V⁶ must be always kept in mind during this step.
